 Boys
|
 9 - 14 Years
|
 4 ft. 5 in. - 5 ft. 3 in.
(View Size Chart)
|
Delivery only in Bangalore
|
Boys
|
9 - 14 Years
|
4 ft. 5 in. - 5 ft. 3 in.
(View Size Chart)
|
Delivery only in Bangalore
Explorer is a bike crafted by considering all the important parameters like bodyweight ratio of a rider and the bicycle, so that it will fit the exploring age youth. This ranges from best one to be a commuter to schools and recreational long distance rides. The geometry is determined by considering measurements of the Indian young generation. Along with it’s stunning looks, the bicycle has high quality, adult-level components, our Explorer boasts high quality parts such as Shimano 21 speed thumb shifters, Gear Set, Crankset and Cassette. With safety as higher priority, this vehicle is equipped with 120 mm front and rear disc brakes; So that the braking requirements will be working in all weather conditions effectively. With 24 inches diameter and 2.125 Inch width MTB tires, it always gives a good area of contact while riding on dirt, gravel, grass, mud, tarmac etc. with the premium level Lockout front suspension equipped with 100 mm travel, riders can improve their skills and be ready for sportive challenges. Explorer comes with dual toned 6 colours options which will be unique with attention to details coloured spokes, seat and bright decals. The internally routed cables are well protected from elements and be reliable for longer years.
*spec applies to all sizes unless otherwise noted
| Frame Set | |
|---|---|
 |
High Tensile Steel, Rigid frame with Hardtail frameset. TIG welded construction. Electrophoretic Deposition (ED) coating on the inside to protect the frame from rust and spray painted. Internal Cable Routing: To provide riders a better streamlined frame, we adopt design of internal cable routing by hiding the cables inside the frame, which can also protect cables from being damaged Seat Post Collar: 30 mm Seat Post: 27.2 mm. Seat Clamp: Alloy 28.6 mm Bottom Bracket: BSA threaded 68 mm (1.37 “ X 24 TPI). A steel TIG welded frame construction gives strong joints and the geometry is a balance between the track machines and the hybrids of the world for comfortable yet fast rides around town. |
| Front Fork | |
|---|---|
 |
High carbon steel suspension fork with 100 mm travel and with a lockout mechanism. Tire Clearance Fork: 50 mm Offset: 50mm available Steerer tube diameter: 1.5" tapered (CTS) Alloy Travel: 100mm Right Side: R2C2-PCS Left Side: Air Spring Crown: A7000 series, Forged Pitch: 70mm Lower: Magnesium Brake: Post Mount 203mm Direct Stanchion tube finish: A7000, Hard anodized Black Quick release axle: ø20-110 Tool type / Tool free |
| Disc Brakes | |
|---|---|
 |
Rear Brake: Piston Road Mechanical Disc, 160mm Rotor Front Brake: Piston Road Mechanical Disc, 160mm Rotor |
| Shifters | |
|---|---|

|
SHIMANO TZ500 21-Speed The SHIMANO TOURNEY TY EZ FIRE Plus Shift/Brake lever combine Reach Adjust, SIS Index shifting, and an OPTICAL GEAR DISPLAY in a durable assembly. |
| Front Derailleur | |
|---|---|
 |
The Shimano 3 speed front derailleur can be used for three chainrings, the largest of which can have 50 teeth. The front derailleur is compatible with modern IG51 Mountain bike chains, which are guided very safely thanks to the fine tuning. The parallelogram is made of light aluminium, the cage plates are made of steel. |
| Rear Derailleur | |
|---|---|
 |
SHIMANO RD-A070 Tourney: 7 Speed. Largest Cog: 28 teeth Chain Wrap capacity: 37 Cage length: short Drivetrain speed: 7 Rear derailleur mount type: 10X1 standard |
| Free Wheel | |
|---|---|
 |
SHIMANO TOURNEY TZ - Multiple Freewheel - HYPERGLIDE - 3x7-speed features a MEGARANGE 14-28 Teeth and 14-34 Teeth range. |
| Chain | |
|---|---|
 |
SHIMANO IG51 Steel Bicycle Chain: 7 Speed 116 Links Narrow.Link size : 1/2\" x 3/32\", Pin Length: 7.1mm. |
| Brake Levers | |
|---|---|
 |
SHIMANO TOURNEY TX - EZ FIRE PLUS - Shift/Brake Lever - 3x7-Speed. Aluminum alloy, Easy three fingers levers. |
| Crankset | |
|---|---|
 |
SHIMANO FC-A073 TOURNEY CRANKSET - 3X7 SPEED DUAL SIS; SG-X chainring. Interchangeable with SHIMANO road front chainring 7-speed system. 170mm crank arm length available. BB-UN26; 50-39-30T, chain guard. |
| Bottom Bracket | |
|---|---|
 |
Splined bottom bracket for use with Shimano Octalink chainsets. Smooth and precise shifting performance with HYPERDRIVE technology. More rigid assembly with sealed cartridge bearings. |
| Wheels | |
|---|---|
 |
Rims: Double walled Alloy. Spokes: 2mm Stainless Black |
| Flat Top Bar Handlebar | |
|---|---|
 |
Double-butting reduces mass by thinning the tube walls where extra material would just be dead weight and retaining strength where it’s needed. Anodized Black 680 mm. Dropping the central bulge relative to the bar’s centerline creates a smooth, flat topped bar. Flat top allows precise mounting of lights and accessories. |
| Tires | |
|---|---|
 |
Hi-Traction Nylon Tire Size: 24 Inch X 2.125 Inch Rear Dropout: 135mm IS Rear dropout. Front Dropout: 100mm IS Front dropout. Tire Clearance at rear: 50 mm |
| Saddle | |
|---|---|
 |
Color-Coordinated, Premium Seat with comfort grade cushion. |
The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit. That’s why you’ll see some overlap in our recommendations. Not every rider who’s 5´8˝, for example, will fit on the same size bike. The best way to find your perfect fit is to consult the experts at your local retailer.
| Product Name | Age | Height | Wheel Size | |
|---|---|---|---|---|
| Flyer | 2 - 4 years | 2 ft. 6 in. - 3 ft. 5 in. | 30 - 41 inches | 14 inches (35 cm) |
| Warrior | 4 - 6 years | 3 ft. 0 in. - 4 ft. 0 in. | 36 - 48 inches | 16 inches (40 cm) |
| Voyager | 6 - 10 years | 3 ft. 6 in. - 4 ft. 2 in. | 42 - 50 inches | 20 inches (50 cm) |
| Explorer | 9 - 14 years | 4 ft. 5 in. - 5 ft. 3 in. | 53 - 63 inches | 24 inches (60 cm) |
| Challenger | 10 years + | 5 ft. 0 in. - 5 ft. 7 in. | 60 - 67 inches | 26 inches (66 cm) |
| Discoverer | 12 years + | 5 ft. 4 in. - 6ft. 1 in. | 64 - 73 inches | 27.5 inches (69 cm) |
| Product Name | Age | Height | Wheel Size | |
|---|---|---|---|---|
| Flyer | 2 - 4 years | 2 ft. 6 in. - 3 ft. 5 in. | 30 - 41 inches | 14 inches (35 cm) |
| Warrior | 4 - 6 years | 3 ft. 0 in. - 4 ft. 0 in. | 36 - 48 inches | 16 inches (40 cm) |
| Voyager | 6 - 10 years | 3 ft. 6 in. - 4 ft. 2 in. | 42 - 50 inches | 20 inches (50 cm) |
| Explorer | 9 - 14 years | 4 ft. 5 in. - 5 ft. 3 in. | 53 - 63 inches | 24 inches (60 cm) |
| Challenger | 10 years + | 5 ft. 0 in. - 5 ft. 7 in. | 60 - 67 inches | 26 inches (66 cm) |
| Discoverer | 12 years + | 5 ft. 4 in. - 6ft. 1 in. | 64 - 73 inches | 27.5 inches (69 cm) |
